Computerized Tensile Testing Machine Multi Test Mode Instrument for Rubber and Textile Strength Evaluation
Key Equipment Functions of Tensile Testing Machine
This machine is designed for static mechanical performance testing and analysis of metallic and non-metallic materials (including composites), covering tests such as tension, compression, bending, shear, peel, tear, load holding, relaxation, and cyclic loading. It determines parameters including maximum force, tensile strength, flexural strength, compressive strength, elastic modulus, elongation at break, and yield strength. It automatically calculates test parameters such as ReH, ReL, Rp0.2, Fm, Rt0.5, Rt0.6, Rt0.65, Rt0.7, Rm, and E. Furthermore, it conducts tests and provides data in accordance with relevant domestic and international standards, such as GB, ISO, DIN, ASTM, and JIS.
Specifications
| Parameter |
Specification |
| Model |
ZT50 / ZT100 / ZT200 / ZT500 / ZT1000 / ZT2000 / ZT5000 |
| Test Force Capacity |
50N / 100N / 200N / 500N / 1000N / 2000N / 5000N |
| Accuracy Class |
Class 0.5 |
| Force Measurement Range |
0.2% ~ 100% FS (full scale) |
| Force Indicating Error |
Within ±0.5% of indicated value |
| Force Resolution |
±1/300,000 of test force, no range switching throughout full scale; resolution remains unchanged across the entire range |
| Deformation Measurement Range |
0.2% ~ 100% FS |
| Deformation Indicating Error |
Within ±0.5% of indicated value |
| Deformation Resolution |
1/200,000 of deformation (up to 1/300,000 for high-end models) |
| Displacement Indicating Error |
Within ±0.5% of indicated value |
| Displacement Resolution |
0.03 μm |
| Force Control Speed Range |
0.005 ~ 5% FS/s |
| Force Control Speed Accuracy |
When speed < 0.05% FS/s: within ±2% of set value; when speed ≥ 0.05% FS/s: within ±0.5% of set value |
| Deformation Control Speed Range |
0.005 ~ 5% FS/s |
| Deformation Control Speed Accuracy |
When speed < 0.05% FS/s: within ±2% of set value; when speed ≥ 0.05% FS/s: within ±0.5% of set value |
| Displacement Speed Range |
0.001 ~ 500 mm/min |
| Displacement Speed Accuracy |
When speed < 0.5 mm/min: within ±1% of set value; when speed ≥ 0.5 mm/min: within ±0.2% of set value |
| Effective Tensile Stroke |
650 mm – 1000 mm (customizable upon request) |
| Effective Compression Stroke |
650 mm – 1000 mm |
| Machine Dimensions (L × W × H) |
(450 × 370 × 1400) mm / (450 × 370 × 1600) mm |
| Machine Weight |
Approx. 90 kg |
| Power Supply |
220V, 50Hz, 0.5 kW |
